The machine combined the method of central rewinding and surface friction rewinding. It can be friction rewinding or center rewinding or combine both ways of rewinding
Machine Characteristic
1.The machine combined the method of central rewinding and surface friction rewinding. It can be friction rewinding or center rewinding or combine both ways of rewinding
2.The machine adopts PLC automatic integrated control
3.A.B rewinding air expansion shaft driven by separate motor Rewinding parameters can be adjusted separately
4.Advanced hydraulic and pneumatic control system. It can realize different ways of rewinding
5.Adopt shaft rotating unload method
Technical parameters
1.Unwinder dia : Φ1100mm
2.Uwinder tension: 10-200N
3.Rewinder dia : Φ600mm
4.Rewinder tension: 10-200N
5.Mini slit width :13mm
6.Paper weight :30-200 g/m2
7.Max width :650mm
8.Max speed: 250m/min
9.Accuracy: ±0.5mm
10.Paper core size :3 inch
